Enphase Grid-tie Inverter
Featuring Remote Monitoring

Enphase offers a Microinverter System for residential and commercial PV applications. A microinverter works by converting DC power from each individual module in a distributed approach, as opposed to the traditional, centralized inverter approach that converts power from strings of modules. This system consists of three components, a microinverter, communications gateway, and a remote monitoring system. The compact microinverters attach directly to solar modules or racking and are wired in parallel directly to a breaker panel. This sends individual module performance information to the Enphase Envoy communications gateway over a wireline network. The Envoy, which is mounted indoors, collects the data and transmits it through a broadband router to the Enlighten™ website. From the Enlighten website, users or installers can view and manage the performance of their solar power system at anytime. The Enlighten website automatically detects any shortfall in energy production, identifies possible causes, and will then send an email to alert the user or installer of this information. Microinverter system components carry an industry leading 15-year warranty.



Enphase offers a Microinverter System for residential and commercial PV applications. A microinverter
works by converting DC power from each individual module in a distributed approach, as opposed to the traditional, centralized inverter approach that converts power from strings of modules. This system consists of three components, a microinverter, communications gateway, and a remote monitoring system. The compact microinverters attach directly to solar modules or racking and are wired in parallel directly to a breaker panel. This sends individual module performance information to the Enphase Envoy communications gateway over a wireline network. The Envoy, which is mounted indoors, collects the data and transmits it through a broadband router to the Enlighten™ website. From the Enlighten website, users or installers can view and manage the performance of their solar power system at anytime. The Enlighten website automatically detects any shortfall in energy production, identifies possible causes, and will then send an email to alert the user or installer of this information. Microinverter system  components carry an industry leading 15-year warranty.

Enphase offers a Microinverter System for residential and commercial PV applications. A microinverter works by converting DC power from each individual module in a distributed approach, as opposed to the traditional, centralized inverter approach that converts power from strings of modules. This system consists of three components, a microinverter, communications gateway, and a remote monitoring system. The compact microinverters attach directly to solar modules or racking and are wired in parallel directly to a breaker panel. This sends individual module performance information to the Enphase Envoy communications gateway over a wireline network. The Envoy, which is mounted indoors, collects the data and transmits it through a broadband router to the Enlighten™ website. From the Enlighten website, users or installers can view and manage the performance of their solar power system at anytime. The Enlighten website automatically detects any shortfall in energy production, identifies possible causes, and will then send an email to alert the user or installer of this information. Microinverter system components carry an industry leading 15-year warranty.

Features include:


  • Increased energy production, every microinverter has Maximum Power Point Tracking (MPPT)

  • High reliability

  • Simplified design, no string calculations needed

  • Allows multiple roof pitches and orientations as well as module types

  • Enables sites with some shade to be viable for solar

  • Safety, no high voltage DC source wiring, reduced fire risk

  • Lower installation cost, no DC disconnect or combiner boxes needed, less wiring time

  • Expansion architecture allows modules to be easily added

  • Module level performance monitoring

M190 – The M190 microinverter is compatible with a wide range of 60 and 72 cell modules up to 230 watts STC. It comes in 208 Vac and 240 models. The 208 Vac model allows 21 microinverters to be connected together in a single branch circuit while the 240 Vac model allows 15 microinverters to be wired in a circuit. The two come with either MC3 or MC4 locking connectors.

M210 – The M210 microinverter is compatible with the 72 cell SANYO N-Series high efficiency module (HIP-200NKHA5, HIP-205NKHA5, HIP-210NKHA5, HIP-215NKHA5). The M210 in combination with SANYO N-Series modules constitutes one of the highest efficiency solar electric systems available. The 208 Vac model allows 18 microinverters to be connected together in a single branch circuit while the 240 Vac model allows 13 microinverters to be wired in a circuit. The M210 comes with MC4 locking connectors.

D380 “Twin Pack” – The D380 “TwinPack” is comprised of two microinverters with switchable inputs (208V or 240V) in a single enclosure and a trunk and drop cabling system. Lower balance-of-system costs and reduced installation time are realized by halving the number of microinverter units and fewer connections and junction boxes. The 12 AWG trunk cable enables 20A branch circuit allowing more modules per branch circuit -240v: 20 modules (10 TwinPacks); 208v: 30 modules (15 TwinPacks). The D380 comes with MC4 and Tyco Solarlock connectors.

Example 6.4kW Enphase Micro IQ7 system, roof mount

Qty Description
18
1
1
1
1
1
1
4
Module Solaria 355 XT-355R with IQ7
Roof Mount IronRidge 2x9W, P, w/edge screen
Flashing Conduit Penetration Flashing
Trunk Cable IQ Trunk Cable Portrait 20 drop
Aggregator Enphase IQ AC Combiner w/Envoy
Sealing Cap Sealing Cap Female
Sealing Cap Sealing Cap Male
Terminator Branch Terminator

Costs do not include shipping, installation or any miscellaneous widgets that may be needed.

Total $14,340
Fed Tax Credit (30%) $(4,302)
Adjusted Total $10,038


Call 406 777-4321 for additional information, products, and pricing.

***********
